You are here: Home page / Cold storage rooms and refrigerators / Blast chillers / TECNODOM - Blast Chiller for 5 GN 1/1 Trays (325x530 mm) or 600x400 mm Pastry Trays
Promoted item
click to enlarge
+ Visualizza altre immagini

TD-P-ATT05EA

TECNODOM - Blast Chiller for 5 GN 1/1 Trays (325x530 mm) or 600x400 mm Pastry Trays

technical card
power supply
Monofase
Volts
V 230/1
frequency (Hz)
50
motor power capacity (Kw)
1,292
net weight (Kg)
92
gross weight (Kg)
98
breadth (mm)
750
depth (mm)
750
height (mm)
890

professional description

TECNODOM - BLAST CHILLER-FREEZER with UNIVERSAL GUIDES for 5 gastro-norm 1/1 or 600x400 mm GRIDS/TRAYS, ALADINO series:

.

  • internal and external structure made of stainless steel , with the exception of the external bottom in galvanized steel;
  • rounded internal corners;
  • high pressure polyurethane injected without environmentally hazardous CFC gases;
  • self-closing door , left-hand hinges and magnetic seal;
  • front panel with electronic control board ;
  • refrigeration unit with opening front grille , easy access for standard cleaning and maintenance;
  • ECOLOGICAL refrigerant gas R290 ;
  • evaporator with anti-corrosion cataphoresis treatment;
  • open door defrosting , without the use of heating elements or hot gas;
  • removable condensation water collection tray ;
  • cycles settable with core probe +3°C, -18°C, -35°C, -40°C;
  • suitable for holding both GN 1/1 grids and 600x400 mm trays. Easy and immediate installation.
  • yield POSITIVE CYCLE +90°+3° Kg.20, NEGATIVE CYCLE +90°-18° Kg.12;
  • Kit of 4 height-adjustable stainless steel feet (60/80 mm high)



TECHNICAL DATA :

  • Energy consumption in cooling (kWh/kg): 0.0564
  • Maximum load capacity for cooling (+90°C to +3°C): 20 kg
  • Cooling time for maximum permissible load (min): 81
  • Energy consumption in freezing (kWh/kg): 0.2163
  • Maximum load capacity for freezing (+90°C to -18°C): 12 kg
  • Maximum temperature of -40°C with an ambient temperature of 30°C;
  • Refrigerant gas: R290
  • Climate class: 4
  • Refrigeration: VENTILATED
  • Defrosting: WITH THE DOOR OPEN
  • Insulation thickness (mm): 60
  • Supply voltage (V): 230 1N
  • Power frequency (Hz): 50
  • Electrical power (W): 1292
  • Material 18/10 STAINLESS STEEL
  • Chamber for 5 GN 1/1 trays (53x32.5 cm) or pastry trays (60x40 cm)
  • Feet height (mm): from 60 to 80
  • Dimensions (mm) LxWxH 750x750x890/910.

Included :

  • A chamber probe
  • A pin probe
  • 5 pairs of universal stainless steel guides GN 1/1 - 600 x 400 mm
  • Standard packaging: pallet + carton

.

Accessories/Optional :

  • universal steel guides - Cod.TD-GUABB.
  • Gastro-Norm 1/1 plasticized grid (mm.530x325) - Cod.TD-GRPLTGN.
  • Kit of 2 wheels with brakes and 2 wheels without brakes - Cod-TD-RUOABB.

.

CE MARK

MADE IN ITALY

acquista
Available models
Code/pictures
Description
Price/Delivery
TD-P-ATT05EA
BLAST CHILLER for 5 GN 1/1 or 600x400 mm TRAYS, POSITIVE CYCLE +90°+3°, 20 kg, NEGATIVE CYCLE +90°-18°, 12 kg, V. 230/1, Kw. 1,292, dim. mm. 750x750x890h
€ 1.936,00VAT escluded € 1.393,92
VAT escluded
Shipping to be calculed
Delivery from 8 to 15 days
technical card
Code/pictures
Description
Price/Delivery
TD-GUABB
TECHNOCHEF - Universal steel guides, Mod. GUABB
€ 33,11
VAT escluded
Shipping to be calculed
Delivery from 4 to 9 days
TD-GRPLTGN
TECHNOCHEF - Plastic coated grill GN 1/1, Mod.GRPLTGN
€ 24,83
VAT escluded
Shipping to be calculed
Delivery from 4 to 9 days
TD-RUOABB
TECHNOCHEF - Kit 2 wheels with brake and 2 wheels without brake, Mod.RUOABB
€ 121,76
VAT escluded
Shipping to be calculed
Delivery from 4 to 9 days
